5 Bedroom Hidden Roof Bungalow House Plan 1500A

A stylish 5 bedroom hidden roof house plan with a total area of 232m², designed on a 21.4m by 14.1m footprint and ideal for a 25.4 x 18.1 meter or 83 x 60 foot plot. The design features a welcoming 7.5m² front porch, spacious 8.1m² lobby, 28m² living room, 13.2m² dining area, and a 19.2m² kitchen with pantry, plus laundry and a rear kitchen porch.

The private wing includes a generous 31.1m² master suite with walk in closet and bath, alongside four additional ensuite bedrooms with built in wardrobes. Finished with a concealed flat roof behind a parapet wall, large windows, and a guest WC, this home blends modern style with practical family living.

Bedrooms
- 5 Bedrooms
Style
- Contemporary
Roof Type
- Hidden Pitched Roof
Storeys
- 1 Storey
Size
- 201 - 260 sqm

Price

$ 349.00

Bedrooms: 5 Bedrooms

Style: Contemporary

Roof Type: Hidden Pitched Roof

Storeys: 1 Storey

Size: 201 - 260 sqm

Key House Plan Features

Bedrooms

5 Bedrooms

Recommended Plot Size

24.5 x 18.1 Meters 83 x 60 Feet

Total House Area

232 Square Meters

House Length

21.4 Meters

House Width

14.1 Meters

Bath

5 Baths1 Visitor WC

Roof Style

Hidden Pitched Roof

Storeys

1 Storey

Full Specifications and Features of this House Plan

House Style

Hidden pitched Roof

House Dimensions

Width: 21.4 Meters

Depth: 14.1 Meters

Total House Area

232 Square Meters

Recommended Plot Size

24.5 x 18.1 meters or

83 x 60 Feet

Roof Features

Hidden Pitched Roof

Galvanized sheet metal roofing

5 - 10 Degrees Pitch

Concrete Gutter system

Front Porch

A large front porch

Mild Steel door

Entry Foyer

Large entry lobby

Lead to living room, dining and passage/other bedrooms

Living Room

Large and Wide Windows for Natural Light

Large Sitting Space

Designed for comfort

Dining

Large dining area

Can accomodate 10 seater dining table

Kitchen

Extensive Worktops

Base Cabinets

Wall Cabinets

Wall Shelves

Gas Cooker area

Fridge

Sink Area

Large window

Pantry

1 dedicated walk in pantry

Shelving and storage

Laundry/ Utility

Dedicated walk laundry with washer and dryer

Comes with shelving

Kitchen Porch

Large kitchen porch at the back

Passage

A passage links the bedroom, bath and the Kitchen, living room, dining with the main entrance foyer

Visitor's Cloak/ Powder Room

1 common cloakroom for visitors

Master Bedroom

1 Master Bedroom

Ensuite

With Bathtub

Built in Walk in Closet

Spacious

Secondary Bedrooms

4 other Bedrooms

All ensuite

Built in Wardrobes

Shower and WC in Bath

Spacious bedrooms

Garage

No Garage

Other Features

Efficient Circulation system

Structure

Reinforced Concrete Columns

Natural Stone strip foundation

Reinforced concrete strip foundation footing

Reinforced concrete ground floor slab

Masonry walling

RC beam

Treated wood roof trusses

Lighting and Electricals

Ceiling Lights

Wall Lights

Feature lighting in living room

Fluorescent ceiling light in kitchen

Waterproof external wall lights.

Multiple power outlets per room

Dedicated TV outlet

Heavy duty power outlets in kitchen and laundry

Two way electrical light switches in bedrooms

Two way light switches in living room,. kitchen and dining

Plumbing

Hot and cold water system

Solar water heater

Robust Septic system

Cold water storage tank

Inspection chambers

Materials and Finishes

Non slip ceramic floor tiles in porches

Matt Ceramic floor tiles

1st grade wall paint

Gypsum celing board

Non slip ceramic tiles in wet areas

Polished Ceramic wall tiles in kitchen

Glossy ceramic wall tiles in bath and other wet areas

What's Included in this House Plan Drawing Set?

The Following are the Included Construction Set Drawings for Building your Home.

1. Cover Sheet

2. Floor Plan

3. Foundation Plan

4. Roof Plan

5. Exterior Elevations

6. Building Section/s

7. Electrical Layout Plan

8. Plumbing Layout Plan

9. Window Schedule

10. Door Schedule

11. Roof Detailing

12. Roof Gutter Detail

13. Roof Eave Detailing

14. Septic Tank Detail

15. Interior Finishes and Materials Schedule

16. Construction General Notes

17. Electrical Notes

18. Plumbing Notes

19. 3D Renders

What's Not Included in these Plan Set

1. Architectural and Engineering Stamps. (Counsil/county submission services).

2. Site Plan since this depends on your unique land shape and orientation.

3. Structural Calculations for your exact soil conditions and local code.

4. Detailed Bill of Quantities (BOQ) and contractor pricing.

After Purchase, What Next?

1. You’ll receive an instant download link in your account page.

2. The download contains all the listed plan drawings combined in one pdf.

3. We recommend printing the drawings in A3 sized paper for legibility.

Construction Ready Drawings

Complete Architectural Drawings ready for construction and site use.

Instant Download

Enjoy fast and Instant Download on all House Plan Orders.

Quality assured

All plans are designed by architects with real world project and site experience.

Secure payment

Your information is protected with encrypted checkout and trusted payment methods.
